| Minimum guaranteed power | R420 |
| 8 ohm/stereo | 4*2000W |
| 4 ohm/stereo | 4*3400W |
| 2 ohm/stereo | 4*4760W |
| 8 ohm/bridge | 2*6800W |
| 4 ohm/bridge | 2*9520W |
| Alternating Current Power Supply | |
| Power | PFC Power |
| Rated power demand | 100-240 ± 10%, 50/60 Hz |
| Operation voltage | 90V-270V |
| Power correction factor cos | > 0.95 @ >500 W |
| Standby | 47W and 0.8A |
| Gain, Sensitivity | 32dB,35dB,38dB,41 dB |
| Maximum Output Voltage/Current | 185V/85A(370V in the BRIDGE MODE) |
| Power Comsumption | 230V(115V in the BRIDGE MODE) |
| Temperature | |
| Environment temperature | 0° – 45C / 32°-113°F |
| Cooling system | Tunnel through cooling system |
| Performance | |
| Frequency Response | 20 Hz – 20 kHz (1 W @ 8 Ω, ± 0.5 dB) |
| Signal-to-Noise Ratio | > 110 dBA (20 Hz – 20 kHz, A weighted) |
| Crosstalk | > 66 dB @ 1 kHz |
| Input Impedance | 10 kg balanced |
| Total Harmonic Distortion (THD) | <0.5% from 1 W to full power (Typical value < 0.05%) |
| Intermodulation Distortion(IMD) | <0.5% from 1 W to full power (Typical value< 0.05%) |
| Damping Factor (8 ohms) | >4000 @ 20-200 Hz |
| Slew Rate | 50 V/ μs @ 8 Ω |
| Front Panel | |
| Indicator LED/per channel | One PCS Green LED: the input signal of XLR ≥ -40dB;
Four pieces Green LED: display the output signal (-20dB,-10dB,-5B,- 3dB) of SPEAKON 1 piece dual LED (Yellow and Red): Protective state/Clip state/Over heat/Over load |
| LED Screen | 1. Display per channel operation mode:
Mono mode, Bridge mode and Stereo mode; Display the temperature of the equipment: the device turns on protective state, and the temperature of the equipment > 75°C; |
| Power Switch | Press “I” -on; Press “O” -off. |
| Dust-proof | Two pieces dust-proof cotton,
it can take off to clearn from the bottom of front pannel |
| Application | |
| Signal in-connection | 4 Channel: One balanced XLR(with lock) female per channel;
Signal in-connection 2 Channel: One balanced XIR(with lock) female and one balanced XLR male per channel. |
| Signal out-connection | One SPEAKON per channel connect to loudspeakers. |
| Power cord | Fixed to the device, and the CSA( cross sectional area) of the cord is 3 x 2.5mm?, and the cord is 1.5 meters long. |
| Multiple-Functions Switch | Two Sensitivity Switches, one Mode Switch and one Clip Switch. |
| Structure (The size and weight depond on different series and shipping demand) | |
| Dimensions | 482x44x380mm3 / 482x44x470mm3 |
| Net weight | 12Kg |
| Packing size | 580x580x119mm3/ 615x615x119mm3 |
| Shipping weight | 14kg |
